Artemis Deep Base LED Emergency Exit Sign Self Test

The ART/30/ST/D is the deep base version of the popular Artemis LED Emergency Exit Sign with Self Test.

  • 5-Year warranty.
  • 30m viewing distance.
  • LiFePO4 battery.
  • Self Test emergency.
  • Deep base to suit 20mm conduit.

Speak to your local account manager

Add to specAddedLogin to Buy Online
Product Code
ART/30/ST/D
Wattage
3.2W
Lumen Output
96 lm
Efficacy
30 lm/W
Emergency Lumen Output
96 lm
Colour Appearance (CCT)
6500K
Frequency
50/60Hz
Colour Rendition (CRI)
Ra > 80
Driver Type
Fixed Output
Emergency Battery Type
LiFePO4
Colour Finish
White RAL9003
Warranty
5 Years
Emergency Battery Guarantee
5 Years
Voltage
220-240V
IP Rating
IP20
LED Life Expectancy
L70B50 36,000 Hours
Power Factor
>0.3
Working Temperature
0°C to 45°C
EM Working Temperature
0°C to 45°C
Beam Angle
110°
Electrical Class
Class II
Approval
UKCA CE
Material (Body/Housing)
Polycarbonate
Material (Diffuser/Cover)
Polycarbonate
Dimensions (mm)
L: 330 x W: 186 x D: 47 mm
Net Weight (KG)
0.68 kg
Barcode
5055807626743
Box Dimensions (mm)
L:337 x W: 190 x D: 54 mm
Box Gross Weight (KG)
0.763 kg
Units/Outer Carton
10
Outer Carton Barcode
15055807626740
Outer Carton Dimensions (mm)
L: 350 x W: 300 x D: 395 mm
Outer Carton Gross Weight (KG)
8.2 kg

Downloads

FILENAME
SINGLE DOWNLOAD
ADD TO ZIP
Artemis Instructions
ART/30/ST/D Spec Sheet
ART/30/ST/D LDT File
Download ZIP
