Rhombus Pro LED Panel

The RBP6628-60 Rhombus Pro is a 6000K high-efficacy recessed LED panel.

  • TP(a) Thermoplastic diffuser.
  • Excellent efficacy – up to 130lm/w.
  • Emergency options & surface mount kits available.
  • Philips driver as standard.

Speak to your local account manager

Add to specAddedLogin to Buy Online
Product Code
RBP6628-60
Wattage
28W
Lumen Output
3640 lm
Efficacy
130 lm/W
Energy class
D
Colour Appearance (CCT)
6000K
Frequency
50/60Hz
Colour Rendition (CRI)
Ra > 80
Driver Type
Fixed Output
Colour Finish
White RAL9003
Warranty
7 Years
Voltage
230V
IP Rating
IP40
IK Rating
IK03
LED Life Expectancy
L80B50 50,000 Hours
Power Factor
>0.9
Working Temperature
-20°C to 45°C
Electrical Class
Class II
Approval
UKCA CE
Material (Body/Housing)
Steel & Aluminium
Material (Diffuser/Cover)
TP(a) Rated Styrene
Dimensions (mm)
L: 595 x W: 595 x D: 26 mm
Length (mm)
595
Width (mm)
595
Depth (mm)
26
Net Weight (KG)
1.65 kg
Barcode
5055807623056
Box Dimensions (mm)
L: 675 x W: 615 x D: 35 mm
Box Gross Weight (KG)
2 kg
Units/Outer Carton
5
Outer Carton Barcode
15055807623053
Outer Carton Dimensions (mm)
L: 690 x W: 630 x D: 190 mm
Outer Carton Gross Weight (KG)
10.7 kg

Downloads

FILENAME
SINGLE DOWNLOAD
ADD TO ZIP
Rhombus Pro Instructions
RBP6628-60 Spec Sheet
