*Bastion LED Panel

This product has been discontinued and replaced by our Razor LED Panel.

You can still find instructions and spec sheet information for this discontinued product below.

Speak to your local account manager

Add to specAddedLogin to Buy Online
Product Code
BLP12336-60
Wattage
36W
Lumen Output
3240 lm
Efficacy
90 lm/W
Energy class
F
Colour Appearance (CCT)
6000K
Frequency
50/60Hz
Colour Rendition (CRI)
Ra > 80
Driver Type
Fixed Output
Colour Finish
White RAL9003
Warranty
5 Years
Voltage
230V
IP Rating
IP20
IK Rating
IK04
LED Life Expectancy
L70B50 50,000 Hours
Power Factor
0.9
Working Temperature
-20°C to 50°C
Electrical Class
Class II
Approval
UKCA & CE
Material (Body/Housing)
Aluminium
Material (Diffuser/Cover)
TP(b) rated Polypropylene
Dimensions (mm)
L: 1195 x W: 295 x D: 9 mm
Length (mm)
1195
Width (mm)
295
Depth (mm)
9
Net Weight (KG)
2.2 kg
Barcode
5055807619820
Box Dimensions (mm)
L: 1270 x W: 325 x D: 35 mm
Box Gross Weight (KG)
2.56 kg
Units/Outer Carton
5
Outer Carton Barcode
15055807619827
Outer Carton Gross Weight (KG)
13.6 kg

Downloads

FILENAME
SINGLE DOWNLOAD
ADD TO ZIP
Bastion Instructions
BLP12336-60 Spec Sheet
Bastion LDT File BLP12336-60
Download ZIP
