Rhombus Plus LED Panel

Red Arrow Rhombus Plus LED Panel
Red Arrow Rhombus Plus Dimensions
Red Arrow Rhombus Plus Energy Label
Red Arrow 2 Years On-Site Warranty
Back

Rhombus Plus LED Panel

The RBX12640-40 Rhombus Plus is a 4000K cost effective, high efficacy LED panel.

  • High efficacy up to 150lm/W.
  • TP(b) diffuser as standard.
  • Emergency options available.

Speak to your local account manager

Add to specAddedLogin to Buy Online
Product Code
RBX12640-40
Wattage
40W
Lumen Output
6000 lm
Efficacy
150 lm/W
Energy class
E
Colour Appearance (CCT)
4000K
Frequency
50/60Hz
Colour Rendition (CRI)
Ra > 80
Driver Type
Fixed Output
Colour Finish
White RAL9003
Warranty
5 Years
Voltage
230V
IP Rating
IP40
IK Rating
IK03
LED Life Expectancy
L80B50 50,000 Hours
Power Factor
>0.9
Working Temperature
-20°C to 45°C
Electrical Class
Class II
Approval
UKCA CE
Material (Body/Housing)
Steel & Aluminium
Material (Diffuser/Cover)
TP(b) Rated Styrene
Dimensions (mm)
L: 1195 x W: 595 x D: 32 mm
Length (mm)
1195
Width (mm)
595
Depth (mm)
32
Net Weight (KG)
3.45 kg
Barcode
5055807622998
Box Dimensions (mm)
L: 1255 x W: 615 x D: 42 mm
Box Gross Weight (KG)
4 kg
Units/Outer Carton
4
Outer Carton Barcode
15055807622995
Outer Carton Dimensions (mm)
L: 1270 x W: 630 x D: 185 mm
Outer Carton Gross Weight (KG)
17.5 kg

Downloads

FILENAME
SINGLE DOWNLOAD
ADD TO ZIP
Rhombus Plus Instructions
RBX12640-40 Spec Sheet
Rhombus Plus LDT File RBX12640-40
Download ZIP
