*Emergency LED Bulkhead

This product has been discontinued and replaced by our Vanguard Emergency LED Bulkhead.

You can still find instructions and spec sheet information for this discontinued product below.

Speak to your local account manager

Add to specAddedLogin to Buy Online
Product Code
LFACLED-2
Wattage
3.5W
Lumen Output
150 lm
Emergency Lumen Output
110 lm
Colour Appearance (CCT)
6500K
Frequency
50Hz
Colour Rendition (CRI)
Ra > 80
Driver Type
Fixed Output
Emergency Battery Type
Ni-Cd
Colour Finish
White
Warranty
3 Years
Emergency Battery Warranty
1 Year
Voltage
230V
IP Rating
IP65
IK Rating
IK06
LED Life Expectancy
L70B50 35,000 Hours
Working Temperature
5°C to 25°C
EM Working Temperature
5°C to 25°C
Electrical Class
Class I
Approval
UKCA CE
Material (Body/Housing)
Polycarbonate
Material (Diffuser/Cover)
Polycarbonate
Dimensions (mm)
L: 350 x W: 110 x D: 65mm
Net Weight (KG)
0.56 kg
Barcode
5055807620536
Box Dimensions (mm)
L: 355 x W: 120 x D: 70 mm
Box Gross Weight (KG)
0.67 kg
Units/Outer Carton
12
Outer Carton Barcode
15055807620533
Outer Carton Dimensions (mm)
L: 375 x W: 375 x D: 300 mm
Outer Carton Gross Weight (KG)
8.45 kg

*Emergency Maintained/Non-Maintained LED Bulkhead

Downloads

FILENAME
SINGLE DOWNLOAD
ADD TO ZIP
Emergency Bulkhead Instructions
Emergency Bulkhead Spec Sheet
