Razor LED Panel

The RZR6636-60 Razor is the latest edge lit LED panel with unique patent designed structure.

  • TP(b)
  • 10mm Thickness
  • 5 Years Warranty
  • Patent Design

Speak to your local account manager

Add to specAddedLogin to Buy Online
Product Code
RZR6636-60
Wattage
36W
Lumen Output
3600 lm
Efficacy
100 lm/W
Energy class
F
Colour Appearance (CCT)
6000K
Frequency
50/60Hz
Colour Rendition (CRI)
Ra > 80
Driver Type
Fixed
Colour Finish
RAL9016
Guarantee
7 Years
Voltage
200-240V
IP Rating
IP20
IK Rating
IK03
LED Life Expectancy
83,000 Hours
Power Factor
0.9
Working Temperature
-20˚C to 40˚C
Beam Angle
120°
Electrical Class
Class II
Approval
UKCA CE
Material (Body/Housing)
Aluminium
Material (Diffuser/Cover)
TP(b) Rated Styrene
Dimensions (mm)
L: 595 x W: 595 x D: 10.2 mm
Net Weight (KG)
2.1 kg
Barcode
5055807626149
Box Dimensions (mm)
L: 630 x W: 675 x D: 30 mm
Box Gross Weight (KG)
2.3 kg
Units/Outer Carton
6
Outer Carton Barcode
15055807626146
Outer Carton Dimensions (mm)
L: 650 x W: 695 x D: 205 mm
Outer Carton Gross Weight (KG)
15.8 kg

Downloads

FILENAME
SINGLE DOWNLOAD
ADD TO ZIP
Razor Instructions
RZR6636-60 Spec Sheet
Download ZIP
